Electric Field Solver Calculator

Superpose two signed point-charge field vectors at a 2D probe, then compute scalar potential, test-charge force, and test potential energy.

CURRENT MODEL

Place two source charges and one field probe

Physics students, electrostatics laboratory teams, and early-stage designers checking field direction and cancellation between two localized charges.

Decision supportedLocate the resultant field vector and potential at one probe point before selecting a test charge, sensor orientation, or safer measurement location.
Resultant field--
Field components--
Field direction--
Electric potential--
Test-charge force--
Test potential energy--

LIVE FIELD VECTORS

Two-source vector superposition

The live coordinate view places both charges and the probe from current inputs, then points each normalized contribution in its calculated direction.

A physicist positions a field probe between two oppositely charged spheres while two directional contributions combine at the probe.
A movable probe separates the vector field contributions from two signed sources before they are combined into one measurement prediction.
Two-charge field superposition ledgerExact current values; full precision is retained before display rounding
Two-charge field superposition ledger for the current inputs
QuantitySymbol or equationCurrent valueUnit

How to use

Build the resultant from signed source contributions

  1. Enter each source charge with its physical sign in microcoulombs.
  2. Place both sources on the x-axis using signed centimetre coordinates.
  3. Enter the probe's signed x and y coordinates without placing it on a source.
  4. Add a signed test charge only if force direction or potential energy is needed.
  5. Read Ex and Ey before interpreting magnitude and direction; cancellation can make angle undefined.
  6. Retain individual source distances and vectors so the superposition can be independently checked.

Electric-field fundamentals

Six rules prevent scalar and vector quantities from being mixed

Positive-source direction
Field points away from a positive point charge at the probe.
Negative-source direction
Field points toward a negative point charge at the probe.
Inverse-square magnitude
Each field magnitude scales as |q|/r squared.
Vector superposition
Ex and Ey add component by component before magnitude is calculated.
Scalar potential
Signed kq/r contributions add algebraically without a direction.
Test-charge independence
An ideal infinitesimal test charge samples but does not alter the source field.

Calculation method

Convert coordinates, solve each source, then combine unlike outputs correctly

Microcoulombs and centimetres are converted to SI before distance and inverse-cube vector scaling. Each displacement vector points from source to probe; the sign of q then determines whether the resulting contribution follows or opposes that displacement.

Field components are summed as vectors. Potential is summed separately as a scalar. The test charge multiplies the completed field for force and the completed potential for potential energy.

Cancellation is not zero potential

Equal positive charges cancel their midpoint field because directions oppose, while their positive scalar potentials reinforce.

Near-source conditioning

Because field scales with inverse distance squared, coordinate uncertainty near a source can dominate the output and should be propagated rather than rounded away.

Probe disturbance

A real probe has finite size and can polarize or redistribute nearby charge. The ideal test-charge assumption is best far from conductive boundaries.

Detailed calculation process

Symbols, current substitution, intermediate quantities, and reconciliation

E = sum[k q_i r_i/r_i^3]; V = sum[k q_i/r_i]; F_t = q_t E; U_t = q_t VCharge and coordinate conversions, individual vectors, sums, magnitude, and potential retain full precision. Direction is omitted at vector cancellation before formatting.
Two-charge solver symbols and defaults
SymbolMeaningDefaultUnit
q1First signed source charge+2microC
q2Second signed source charge-1microC
r_iSource-to-probe displacementcalculatedm
EResultant field vectorcalculatedV/m
VScalar electric potentialcalculatedV
q_tSigned test charge+1nC

    Waiting for valid inputs.

    Interpretation

    Use components for orientation and potential for energetic comparison

    The field angle reports the direction a positive test charge would accelerate. A negative test charge accelerates oppositely. Potential can remain large where the vector field cancels, so sensor force and discharge-energy questions must not substitute one output for the other.

    Evidence and measurement

    Preserve charge geometry and environmental assumptions

    Record source construction and charge estimate, coordinate datum, probe location and dimensions, humidity and surrounding dielectric, conductor boundaries, grounding state, test-charge sign, instrument bandwidth, uncertainty, and whether charges remained stationary during measurement.

    Scope and limitations

    Where the point-charge vacuum model stops

    • Finite conductors, charge redistribution, images, and grounded boundaries
    • Dielectric polarization, interfaces, anisotropy, and nonlinear response
    • Time-varying fields, radiation, magnetic force, and retardation
    • Probe loading, finite sensor volume, and spatial averaging
    • Air ionization, corona, breakdown, or discharge paths
    • Electrical safety or insulation-system certification

    Two stationary point charges in vacuum, positioned on the x-axis, with an observation point in the x-y plane. Superposition is electrostatic; finite conductor size, dielectric boundaries, and induction are excluded.

    Key terminology

    Electrostatic solver glossary

    Point charge
    Ideal source whose physical extent is negligible relative to distance.
    Electric field
    Force vector per unit positive test charge.
    Electric potential
    Scalar potential energy per unit charge.
    Superposition
    Linear addition of independent source contributions.
    Cancellation point
    Location where field vectors sum to zero.
    Coulomb constant
    SI proportionality 1/(4 pi epsilon0) for vacuum point charges.

    Practical cases

    Two probe locations with different physical meaning

    Opposite-charge probe

    At the default probe, unequal signed sources produce a 3.124468 MV/m resultant at 33.499657 degrees and 140.272100 kV potential. Both vector and scalar outputs matter.

    Symmetric positive midpoint

    Equal positive charges at -5 cm and +5 cm cancel the field at the origin. The angle is undefined, yet potential remains positive and a moved charge can still exchange energy.

    Important note

    Ideal source math is not high-voltage clearance approval

    Use the solver for electrostatic reasoning and cross-checks. Real insulation and exposure decisions require conductor geometry, material, environment, transient, and breakdown evidence.

    Frequently asked questions

    Why are electric fields added as vectors?

    Each charge produces a direction and magnitude at the probe. Components must be summed before computing the resultant magnitude and angle.

    Why is electric potential added as a scalar?

    Potential is energy per unit charge and has no spatial direction. Signed contributions therefore add algebraically even when field vectors point differently.

    Can the field be zero while potential is not zero?

    Yes. Equal positive charges at their midpoint cancel field vectors but add positive potential. Field cancellation does not imply zero potential.

    What happens for a negative test charge?

    Its force direction is opposite the electric field and its potential energy qV changes sign. The source field itself is unchanged.

    Why can the probe not sit on a point charge?

    The ideal point-charge expressions divide by r squared or r. At r=0 the ideal model is singular and cannot return a finite physical result.

    Can this model conductors or dielectric interfaces?

    No. Conductors redistribute charge and dielectrics polarize, altering boundary conditions. Those cases need geometry-aware numerical field analysis or an analytic boundary solution.
