Reliability versus restoration
Increasing MTBF lowers lambda and shifts probability toward fewer failures. Reducing MTTR can change the integer count needed to breach even when failure frequency is unchanged.
Probability
System Availability Risk Calculator
Screen the probability that planned downtime plus Poisson-modeled corrective failures will reach a downtime threshold, with expected downtime and probability-weighted exposure.
DOWNTIME-THRESHOLD TAIL RISK
Measure the chance of crossing a consequential downtime boundary
The model converts horizon and MTBF into an expected failure count, maps each count to downtime through a fixed restoration duration, and sums every count that reaches the entered threshold.
Threshold breach probability -
Probability-weighted exposure -
Failures needed to trigger -
Expected failure count -
Expected total downtime -
Expected availability screen -
LIVE DECISION RECORD
Failure-count threshold ladder
Each row links a possible failure count to total downtime, exact Poisson probability, cumulative mass, and threshold status.
| Failures | Total downtime | Exact probability | Cumulative probability | Threshold status |
|---|
CURRENT CALCULATION PROCESS
Formula, current substitution, intermediate values, and reconciliation
lambda = H/MTBF; m = max(0, ceil((T-D_p)/MTTR)); Risk = P(N >= m), N ~ Poisson(lambda)
| Symbol | Meaning and unit | Current value |
|---|---|---|
| horizonHours | Risk horizon (hours) - Calendar exposure period for the failure-count screen. | 2160 |
| mtbfHours | Mean time between failures (hours) - Constant-rate failure spacing used to set the Poisson mean. | 600 |
| mttrHours | Restoration time per failure (hours) - Fixed downtime increment assigned to each modeled failure. | 7 |
| plannedDowntimeHours | Planned downtime (hours) - Known downtime already consuming part of the threshold. | 10 |
| downtimeThresholdHours | Downtime risk threshold (hours) - Total downtime level that defines the adverse event. | 32 |
| thresholdExposure | Consequence if threshold is reached - Contract, margin, or recovery exposure in one currency. | 180000 |
Waiting for valid inputs.
WHO THIS MODEL SERVES
A scoped decision aid, not a universal forecast
Primary audience: Reliability, operations-risk, insurance, and SLA teams screening a count-driven downtime threshold.
Decision boundary: Use for a constant-rate Poisson failure count and fixed repair duration; do not treat it as a safety-integrity calculation or repair-duration distribution.
HOW TO RUN THE RISK SCREEN
Five steps from horizon to escalation probability
- Choose the exposure horizon and confirm MTBF uses operating hours compatible with it.
- Enter a restoration duration that represents the scenario, not an optimistic best case.
- Separate committed planned downtime from random corrective events.
- Define the downtime threshold from an SLA, production, cash, or recovery decision.
- Inspect the integer trigger count and retain the table with the consequence source.
RISK FUNDAMENTALS
Five concepts required by the tail model
- Poisson mean
- lambda=H/MTBF is the expected count under a constant event rate.
- Trigger count
- The smallest whole failure count that reaches the remaining downtime threshold.
- Upper tail
- The combined probability of the trigger count and every more severe count.
- Expected downtime
- Planned hours plus lambda times repair hours; it is distinct from threshold probability.
- Consequence exposure
- A conditional amount attached to the threshold event, not an event probability.
FORMULA AND DEFAULT SUBSTITUTION
Convert a time boundary into a count boundary
lambda=H/MTBF; m=ceil((T-D_p)/MTTR); P(breach)=1-sum from k=0 to m-1 e^(-lambda)lambda^k/k!
Defaults give lambda=2160/600=3.6 failures. The unplanned hours needed are 32-10=22, so m=ceil(22/7)=4 failures. The live risk is P(N>=4), and expected downtime is 10+3.6 x 7=35.2 hours.
DEEPER RISK ANALYSIS
Three controls that can move the tail
Threshold cliff
Because failures are whole events, a small threshold or repair-time change can move m by one and create a discrete jump in risk.
Severity calibration
The weighted exposure is meaningful only when the entered consequence corresponds to the same breach definition, horizon, and accounting basis.
WORKED RISK CASES
Two boundaries with different escalation logic
Quarterly production SLA
With lambda=3.6 and four failures needed, the risk team can compare a spares project that cuts repair time with a reliability project that increases MTBF; each acts on a different side of the trigger equation.
Planned-stop saturation
If the threshold is 8 hours while planned downtime is 10 hours, the event is already true. A 100% result is correct and signals that the threshold definition or maintenance commitment needs review.
RISK TERMINOLOGY
Six terms for the decision record
- Failure intensity
- Constant event rate represented by 1/MTBF.
- Poisson process
- Independent event-count model with stationary rate.
- Downtime threshold
- Total planned-plus-corrective hours defining the adverse event.
- Trigger failures
- Minimum corrective count needed to cross that boundary.
- Tail risk
- Probability assigned to all counts at or beyond the trigger.
- Weighted exposure
- Tail probability multiplied by one conditional consequence amount.
EVIDENCE RETENTION
Keep event and consequence definitions aligned
Retain failure timestamps, operating-hour denominator, repair-close criteria, planned-stop calendar, threshold authority, and consequence calculation. Record whether repeated alarms were deduplicated into incidents.
LIMITS AND EXCLUSIONS
Where the screen stops
- Failure arrivals use one constant Poisson rate with independent increments.
- Every failure receives the same fixed repair duration.
- Overlapping failures, shared causes, queueing, and resource contention are excluded.
- The entered threshold exposure is applied once, not by downtime severity.
- Safety, regulatory, and contractual risk require domain-specific review.
RELIABLE SOURCES
Primary references for count and availability assumptions
DOWNTIME-RISK FAQ
Questions about the breach tail
Why use a Poisson count instead of MTBF/(MTBF+MTTR)?
Availability gives an average time share; risk asks for a tail event. A Poisson count model can sum the chance of enough failures to cross a specified downtime threshold.
What if planned downtime already exceeds the threshold?
The adverse event is already triggered, so the calculator returns 100% threshold probability with zero additional failures required.
Why is repair time fixed per failure?
It keeps the threshold mapping auditable. If repair durations vary materially, use a compound count-severity model or simulation.
Does probability-weighted exposure equal expected loss?
Only if the entered consequence applies once whenever the threshold is reached and no other state-dependent costs matter.
Can I enter a wear-out asset?
Not without caution. The model assumes a constant failure rate; age-dependent hazard violates the Poisson-process premise.
Why cap expected failures at 200?
The page is a screening tool with explicit exact summation; very high counts need a more suitable numerical or continuous approximation and a reviewed model.
IMPORTANT RISK NOTE
A stable rate is a hypothesis, not a label
Check for trends, clustering, maintenance effects, and common causes before using the Poisson tail. Escalation decisions should retain uncertainty around both event frequency and consequence.
